Type |
HMD-250h |
HMD-350h |
HMD-450h |
HMD-600h |
|
Film width |
Max 250mm |
HMD-350 |
Max 450mm |
HMD-600 |
|
Bag length |
70-280mm |
70-300mm |
70-400mm |
HMD-600 |
|
Bag width |
30-110mm |
50-160mm |
50-210mm |
HMD-600 |
|
Product height |
Max 40-60mm |
Max 40-60mm |
Max 75mm |
HMD-600 |
|
Fim roll diameter |
Max 320mm |
|||
|
Packing speed |
40-230bag/min |
40-230bag/min |
40-180bag/min |
HMD-600 |
|
Power220V 50/60Hz |
2.6kW |
2.8kW |
3.2kW |
3.4kW |
|
Machine size（L×W×H） |
3877×670×1390mm |
3980×830×1390mm |
4020×888×1450mm |
4280×1050×1450mm |
|
Machine weight |
450kg |
580kg |
650kg |
700kg |
|
Optional device |
Coding machine, Gas-filling device, Cake falling device, Sorting machine |
|||
|
Packaging material |
For example single-layer heat sealing BOPP or composite film such as OPP composite PE, PET composite PEF |
|||
|
Bag type |
Back-sealed package (hanging hole round hole/butterfly hole can be customized ) |
|||
|
Horizontal sealing /Blade grain |
Cutter edge serrated/flat edge plus V easy tear |
|||
